ML24 Series MPPT Controller
• MPPT with up to 99.9% efficiency • LED fault indicators and an LCD screen • Historical data storage function • Different charging program options • All communications are electrically isolated • TVS lighting protection
Product Details
1. With the advanced dual-peak or multi-peak tracking technology, when the solar panel is shadowed or part of the panel fails resulting in multiple peaks on the I-V curve, the controller is still able to accurately track the maximum power point.
2. A built-in maximum power point tracking algorithm can significantly improve the energy utilization efficiency of photovoltaic systems, and raise the charging efficiency by 15% to 20% compared with the conventional PWM method.
3. A combination of multiple tracking algorithms enables accurate tracking of the optimum working point on the I-V curve in an extremely short time.
4. The product boasts an optimum MPPT tracking efficiency of up to 99.9%.
5. Advanced digital power supply technologies raise the circuit's energy conversion efficiency to as high as 98%.
6. Charging program options are available for different types of batteries including gel batteries, sealed batteries, open batteries, lithium batteries, etc.
7. The controller features a limited current charging mode. When the solar panel power exceeds a certain level and the charging current is larger than the rated current, the controller will automatically lower the charging power and bring the charging current to the rated level.
Related document：
-
File size: 1.6MB
-
File size: 1.1MB
Q1:What kind of certificates you have for your solar controllers?
A1:Our products are fully certified,with CE,RoHS,and other certifications.
Q2:Can I have a sample order for your products?
Yes,we welcome sample order to test and check quality.Mixed samples are acceptable.
Q3:What about the lead time?
Sample:1-2 working days
Order:within 7 working days depending on the order quantities
OEM order:15-20 working days after confirming the sample.
Q4:How to deal with the faulty?
Firstly,All our products are produced in a strict quality control system,have gone through 28 functional tests,at least three comprehensive tests,and the defective rate is less than 0.2%.
Secondly,if something goes wrong with the products.please send back photos or videos of defectives,our engineers will analyze which part has a products.
During the guarantee period,we will send replacements with new orders for small quantities.
For defective batch products,we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation.
If over the guarantee period,you can buy the replacements from us.
